Turbo Mower Offset

A well designed and constructed range, the Turbo Mower Offset is built with durability and ease-of-use in mind – a low maintenance machine that is simple to operate.

Key Features

1.6m, 2.2m and 2.5m cutting widths
Three point linkage mounting
Left or right hand cutting options available
PTO overrun protection, safety breakaway and double-skin protection
132 degrees of head movement
Vertical and horizontal hydraulic adjustment
Fuel-efficient, high-performance double spiral rotor
Cutting height of 30mm – 80mm
Maximum cutting diameter of 50mm

Product Specification

Standard = Standard Optional = Optional Not Available = Not Available

Models	160	220	220HD	250HD
Working Width	1.6m / 5’3”	2.2m / 7’2”	2.2m / 7’2”	2.5m / 8’2”
Weight	610kg / 1345lbs	710kg / 1565lbs	1060kg / 2310lbs	1260kg / 2779lbs
Front Protection	Steel Flap	Steel Flap	Steel Flap	Steel Flap
Rear Protection	Rubber Flap	Rubber Flap	Rubber Flap	Rubber Flap
Linkage	Cat 11	Cat 11	Cat 11/111	Cat11/111
PTO Speed (rpm)	540	540	540	540
No of Belts	3	3	4	5
Front Mount	Not Available	Not Available	Not Available	Not Available
No of Flails (Whale Tail)	16	22	22	24
Width of Flails	110mm / 4⁵/₁₆	110mm / 4⁵/₁₆	110mm / 4⁵/₁₆	135mm / 5⁵/₁₆
Power Requirements (min)	50hp	60hp	90hp	95hp
Cutting Height	30-80mm / 1³/₁₆” – 3¹/₈”	30-80mm / 1³/₁₆” – 3¹/₈”	30-80mm / 1³/₁₆” – 3¹/₈”	30-80mm / 1³/₁₆” – 3¹/₈”
Roller Size	140mm / 5½”	140mm / 5½”	170mm / 6¹¹/₁₆”	170mm / 6¹¹/₁₆”
